ATOM SPEAKER PAIR

Handcrafted to Order

Every Atom Speaker Pair is individually handcrafted, assembled, voiced, tested, and carefully packaged before shipment.

Estimated Build Time: 6–8 weeks

A Complete High-Efficiency Loudspeaker System

The Atom is a complete two-way loudspeaker designed around the same principles that define Shinjitsu Audio: natural timbre, effortless dynamics, high sensitivity, and a presentation that allows the loudspeaker itself to disappear.

Rather than dividing the music across multiple drivers and crossover regions, the Atom uses a deliberately simplified architecture that preserves coherence through the most important part of the musical spectrum.

The result is a presentation that is immediate without becoming aggressive, detailed without sounding analytical, and dynamic without requiring large amounts of amplifier power.

Continuum™ Tuning Architecture

The Hiro incorporates the proprietary Continuum™ Crossover Architecture, allowing the horn and woofer to operate as a unified system rather than as separate acoustic sources.

The system is voiced for:

• Natural vocal presence

• Realistic instrumental timbre

• Controlled bass

• Stable imaging

• Low-level detail

• Effortless dynamic expression

The final voicing is completed before shipment so the speaker arrives ready to perform as a complete system.

Designed for Real Music

The Atom was developed around the qualities that make recordings believable rather than merely impressive.

Vocals have body and presence.

Acoustic instruments retain their natural texture.

Electric guitars remain articulate without becoming hard.

Cymbals retain metallic realism without excessive brightness.

Bass is controlled, textured, and integrated rather than exaggerated.

The objective is simple:

The loudspeaker should disappear and leave the performance behind.

What's Included

• Matched pair of Atom loudspeakers

• Integrated horn assemblies

• Matched woofer systems

• Continuum™ crossover networks

• Premium internal wiring

• Hardwood detailing - with choice of hardwood faces

• Product Care & Assembly Guide

• Height - 20 inches
• Width - 6 inches
• Depth - 9.5 inches
• Horn type - B&C ME20 / 6-inch horn
• Compression Driver - Cd171 FE/PK Beyma
• Weight - 16.35 Lbs each speaker
• Frequency response - 50 Hz to 20 kHz

• Shipping box dimensions - 18x18x24
• Shipping weight - 35 pounds

Construction

Each Atom Speaker is individually built and finished by hand.

Natural hardwood components are selected individually, so grain pattern and color will vary slightly from pair to pair. These variations are inherent to real wood and make every Atom Speaker visually unique.

Technical Highlights

• Complete high-efficiency two-way loudspeaker

• Horn-loaded high-frequency system - ME45 6 inch B&C

• Continuum™ crossover architecture


• Extended Range CHR 70 Mark Audio woofer choice of copper, silver or black cone



• Baltic Birch Handcrafted enclosure

• Premium Horn x2 desin plinth sized ATOM Scale to fit

• Designed for low to moderate-power amplification

• Sold as a matched stereo pair



Amplifier Compatibility

The Atom's high sensitivity makes it particularly well suited to:

• SET amplifiers

• 300B and similar low-power tube amplifiers

• Push-pull tube amplifiers

• Class A solid-state amplification

• Conventional integrated amplifiers

Large amplifier power is not required to achieve realistic listening levels.

Important Information

The Atom is sold as a complete Shinjitsu Audio production loudspeaker.

Cabinet drawings, internal dimensions, port specifications, crossover schematics, bracing layouts, damping methods, and other proprietary construction information are not
provided.

Shipping

Flat Rate: $199

The Atom Speaker Pair is carefully packed for safe transport.

Final shipping cost and delivery method depend on destination and current freight requirements.

A Product Care & Assembly Guide is included with every pair.

Speaker cables are not included.
