Atom™ Acoustic Engine

Designed to reproduce the Atom Speaker or integrate into compact loudspeaker projects — this is not a standalone speaker.

Small Loudspeaker. Full-Range Performance. Precision Engineered.

The Atom™ Acoustic Engine brings the engineering found in the complete Atom Speaker to builders and enthusiasts seeking exceptional performance from compact loudspeaker systems.

Combining a precision constant-directivity horn, high-performance compression driver, and the Shinjitsu Audio™ Continuum Crossover Architecture, the Atom™ Acoustic Engine delivers effortless dynamics, exceptional vocal realism, and remarkably low distortion while integrating seamlessly with the Mark Audio CHR70 full-range driver.

Every Acoustic Engine is fully assembled, wired, tested, and ready for installation into a properly constructed enclosure.

Designed As A Complete Acoustic System

The Atom™ Acoustic Engine is considerably more than a horn and compression driver. Every component has been engineered to function as a complete acoustic system with the supplied crossover network and Continuum tuning architecture.

Each Atom™ Acoustic Engine includes:

  • B&C ME20 Constant Directivity Horn
  • Beyma CD171 FE/PK Compression Driver
  • Shinjitsu Audio™ Continuum Crossover Architecture
  • Premium Air-Core Inductors
  • Polypropylene Film Capacitors
  • Non-Inductive Precision Resistors
  • Integrated Precision L-Pad Attenuation Network
  • Heavy Gauge Oxygen-Free Copper Internal Wiring
  • Gold-Plated Five-Way Binding Posts
  • Furniture-Grade Baltic Birch Internal Structure
  • Premium Hardwood Plinth

Designed specifically for the Atom loudspeaker platform while remaining adaptable to other compact loudspeaker projects.

Specifications

Product Atom™ Acoustic Engine
System Type Passive Constant-Directivity Mid / High Frequency Compression Engine
Frequency Response Approximately 3 kHz – 20 kHz (Application Dependent)
Recommended Integration Mark Audio CHR70 Full-Range Driver
Horn B&C ME20 Constant Directivity
Coverage Pattern 90° Horizontal × 60° Vertical
Compression Driver Beyma CD171 FE/PK
Diaphragm Material Polymer
Voice Coil 1.7 in (44 mm)
Nominal Impedance 8 Ohms
Sensitivity Approximately 107 dB
Crossover Architecture Shinjitsu Audio™ Continuum Crossover
Crossover Topology Optimized Acoustic Alignment
Level Matching Integrated Precision L-Pad Attenuation Network
Components Air-Core Inductors • Polypropylene Film Capacitors • Non-Inductive Precision Resistors
Input Connection Gold-Plated Five-Way Binding Posts
Internal Wiring Heavy Gauge Oxygen-Free Copper
Internal Structure Furniture-Grade Baltic Birch
Plinth Material Choice of Premium Hardwood Species (See Available Finishes)
Finish Satin Black with Natural Hardwood Plinth
Operation Passive — No External Power Required
Application Atom Speaker • Builder Series • Compact DIY Loudspeaker Projects
Designed & Assembled Arizona, USA

Acoustic Performance

  • Controlled-directivity horn loading for improved imaging.
  • Exceptional vocal intelligibility and transient response.
  • Wide listening window with consistent tonal balance.
  • Extremely low distortion throughout the operating range.
  • Effortless dynamics from compact loudspeaker systems.
  • Engineered specifically for seamless integration with the Mark Audio CHR70.
  • Optimized for both tube and solid-state amplification.

Available Hardwood Species

  • Morado (Pau Ferro)
  • Black Limba
  • Canarywood
  • Ambrosia Maple
  • Cherry
  • Walnut
  • Red Oak
  • White Oak
  • Brazilian Hickory
  • Baltic Birch

Available hardwood species may vary based upon current inventory.

Designed, assembled, tested, and individually inspected by Shinjitsu Audio.

The Atom™ Acoustic Engine incorporates the same engineering philosophy found throughout every Shinjitsu Audio loudspeaker: controlled directivity, seamless integration, natural tonal balance, and uncompromising musical realism in a remarkably compact format.

```
